768V Rechargeable Lithium Ion Battery Energy Storage System For Commercial Industrial

Brand Name : BATTLINK

Model Number : 215KWh

Certification : UN38.3

Place of Origin : China

MOQ : 1pcs

Price : Nigotiation

Payment Terms : T/T, L/C

Supply Ability : 10000pcs per month

Delivery Time : 30 days

Packaging Details : Carton

Rated Voltage(V) : 768

Rated Capacity(Ah) : 280

Rated Battery Capacity(kWh) : 215

Operating Temperature(°C) : -20-55

Chemistry : LiFePO4

Charge and Discharge Rate（P） : ≤0.5

DOD : 95%

Cycle Lifetime at EOL 70% : >6000cycles

Contact Now

215KWh Commercial & Industrial rechargeable energy storage system

Product presentation

The BATTLINK215 commercial & industrial energy storage series adopts the All in one design concept.The cabinet is integrated with battary management system (BMS),ener-gy management system (EMS),modular power conversion system(PCS),and fireprolec-tian system. The system’s capecify is up to 241 kWh and the power is up to 100 kW. The modular design allows for flexible expansion, adapting to various scenarios such as power expansion, backup power supply, and black start(The ability to restore power without relying on the help of other networks after the power system is out of service due to a fault.).

The BATTLINK 215 intelligent energy storage series is directly connected to the low-voltage side, and can realize multi-connection cabinets and flexible expansion. It can be used in a wide range of industrial and commercial application scenarios.

Product features:

  • On&off grid switch time 0.02S, Key load uninterrupted power supply
  • 5-in-1 fire detection, comprehensive monitoring
  • Max. 24x in parallel
  • Max. round trip efficiency 93%
  • Max. continuous discharge current 160A

Performance parameter

Product Model BATT-CL-100/215
Rated Battery Capacity(kWh) 215
Rated Voltage (V) 768
Voltage Range (Vdc) 720-840
Charge and Discharge Rate(P) ≤0.5
Max. Round Trip Efficiency 93%
DOD 95%
Cooling Strategy Industrial Air Conditioning
Cycle Lifetime at EOL 70% ＞6000 cycles
Fire Fighting System Perfluorohexanone/Aerosol
Rated Power(kw) 100
Rated AC Voltage(Vac) 380/400
AC Voltage Range -15%~+10%
Rated Grid Frequency(Hz) 50/60
Size[Wx D x H,mm] 1520*1270*2117
Weight(T) 2.6
Enclosure Protection Rating IP55
Operating Temperature Range (°C) -20-+55(>45 drop)-20-+55(>45 drop
Operating Humidity Range 0-95%
Maximum Working Altitude(m) ≤4000(>2000 drop)
Communication Interface RS485,EthernetRS485,Ethernet
Protocol Modbus RTU, Modbus TCP,IEC104

Battery Module parameter

Battery Type LFP,3.2V280Ah
Battery Module 64V280Ah,17.92kWh,130kg
Battery Pack Configuration 240S1P
Energy(kwh) 215.4
Standards Compliant VDE4105 G98 G99 EN50549-1 BOS-P-01C10/11 UN38
